TECHNICAL REFERENCE
Compressor type | Nominal power of motor | Air displacement | cylinders *diameter * stroke | Fuel injection | Power source | Electrical parameter | Crankcase heater | Oil supply mode | Weight (including chilled oil) | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| MODEL | HP/KV | Low pressure | High tension | Unit：mm | Unit：L | V/∅/HZ | Maximu working current | Startin g/locking current | Unit：W | Unit：kg | |
| BF-3PZ-001A | 3/2.2 | 16.24 | 2xØ55x39.3 | 1.5 | 380˜ 420/Y/3/50 440˜ 480/Y/3/60 | 8.5 | 37 | 110 | Centrifuga lubrication | 70 | |
| BF-4PZ-001B | 4/3.0 | 2.72 | 4xØ46x39.3 | 2.0 | 10.7 | 53 | 115 | 84 | |||
| BF-5PZ-001 | 5/3.7 | 26.84 | 4xØ50x39.3 | 2.0 | 13.5 | 62.2 | 115 | 84.5 | |||
| BF-7.5PG-002 | 7.5/5.5 | 26.84 | 4xØ50x39.3 | 2.0 | 15.9 | 62.2 | 115 | 84.5 | |||
| BF-6PZ-003 | 6/4.4 | 26.84 | 4xØ50x39.3 | 2.0 | 15.9 | 82.4 | 115 | 88.5 | |||
| BF-9PG-004 | 9/6.6 | 32.48 | 4xØ55x39.3 | 2.0 | 20 | 82.4 | 140 | 90.5 | |||
| BF-6PZ-005A | 6.2/4.4 | 34.73 | 4xØ55x39.3 | 2.6 | 380˜ 420/Y/3/50 440˜ 480/Y/3/60 | 14 | 39/68 | 140 | Centrifuga lubrication | 129 | |
| BF-10PG-005B | 10/7.5 | 34.73 | 4xØ46x42 | 2.6 | 21 | 539-99 | 140 | 139 | |||
| BF-8PZ-005 | 8/5.5 | 41.33 | 4xØ60x42 | 2.6 | 17 | 49/81 | 140 | 134 | |||
| BF-12PG-006 | 12/8.8 | 41.33 | 4xØ60x42 | 2.6 | 24 | 69/113 | 140 | 141 | |||
| BF-10PZ-007 | 10/7.5 | 48.5 | 4xØ65x42 | 2.6 | 21 | 59/99 | 140 | 139 | |||
| BF-15PG-008 | 15/10.5 | 48.5 | 4xØ65x42 | 2.6 | 31 | 59/99 | 140 | 142 | |||
| BF-12PZ-009 | 12/8.8 | 56.25 | 4xØ70x42 | 2.6 | 24 | 69/113 | 140 | 141 | |||
| BF-20PG-010 | 20/15 | 56.25 | 4xØ70x42 | 2.6 | 37 | 97/158 | 140 | 150 | |||
| BF-15PZ-011 | 15/10.5 | 73.6 | 4xØ70x55 | 4.5 | 380˜ 420/Y/3/50 440˜ 480/Y/3/60 | 31 | 81/132 | 140 | Oil pum lubrication | 197 | |
| BF-25PG-012 | 25/18.5 | 73.6 | 4xØ70x55 | 4.5 | 45 | 116/193 | 140 | 205 | |||
| BF-20PZ-013 | 20/15 | 84.5 | 4xØ70x55 | 4.5 | 37 | 97/158 | 140 | 200 | |||
| BF-30PG-014 | 30/22 | 84.5.6 | 4xØ70x55 | 4.5 | 53 | 135/220 | 140 | 209 | |||
| BF-25PZ-015 | 25/18.5 | 110.5 | 6xØ70x55 | 4.25 | 380˜ 420/Y/3/50 440˜ 480/Y/3/60 | 45 | 116/193 | 140 | Oil pum lubrication | 237 | |
| BF-35PG-016 | 35/25.5 | 110.5 | 6xØ70x55 | 4.25 | 61 | 147/262 | 140 | 248 | |||
| BF-30PZ-017 | 30/22 | 126.8 | 6xØ75x55 | 4.75 | 53 | 135/220 | 140 | 248 | |||
| BF-40PG-018 | 40/30 | 126.8 | 6xØ75x55 | 4.25 | 78 | 180/323 | 140 | 247 | |||
| BF-40PZ-019 | 40/30 | 126.8 | 6xØ75x55 | 4.25 | 78 | 180/323 | 140 | 247 | |||
| BF-50PG-020 | 50/37 | 126.8 | 6xØ75x55 | 4.25 | 78 | 180/323 | 140 | 247 | |||
| BF-20PGDS-023 | 20/15 | 73.6 | 36.8 | 6xØ70/70x55 | 4.75 | 380˜ 420/Y/3/50 440˜ 480/Y/3/60 | 37 | 97/158 | 140 | Oil pum lubrication | 235 |
| BF-25PZDS-024 | 25/18.5 | 84.5 | 42.3 | 6xØ70/70x55 | 4.75 | 45 | 115/193 | 140 | 248 | ||
| BF-30PGDS-025 | 30/22 | 101.1 | 50.5 | 6xØ70/70x55 | 4.75 | 53 | 135/220 | 140 | 249 | ||
